ARM StackGuard - Stack Canary
Nearly every introduction to exploitation covers Aleph One's classic article "Smashing the Stack for Fun and Profit"(pdf1, pdf2), which explains the basics of exploiting stack-based buffer overflows.
In this article, I'll explore the basic Buffer overflow protection mechanism based on stack canary.
gcc -fstack-protector#
linux - Stack Guard and Stack Smashing Protection - canaries, memory
Use compiler flags for stack protection in GCC and Clang | Red Hat Developer
There are several methods to protect against this scourge, regardless of the C/C++ programmers' negligence. MSVC has options like
- /GZ (Enable Stack Frame Run-Time Error Checking) - Deprecated, use
/RTC (Run-Time Error Checks)instead. - /RTC (Run-time error checks) -
/RTCsEnables stack frame run-time error checking
GCC - Instrumentation Options
-fstack-protector: Emit extra code to check for buffer overflows, such as stack smashing attacks. This is done by adding a guard variable to functions with vulnerable objects. This includes functions that call alloca, and functions with buffers larger than or equal to 8 bytes. The guards are initialized when a function is entered and then checked when the function exits. If a guard check fails, an error message is printed and the program exits. Only variables that are actually allocated on the stack are considered, optimized away variables or variables allocated in registers don't count.
Aggressive options:
-fstack-protector-all-fstack-protector-strong-fstack-protector-explicit
Related options:
-fstack-check-fstack-clash-protection-fsplit-stack
sysvabi64 - 9 Program Loading and Dynamic Linking - 9.4 GNU Indirect Functions - 9.4.2 IFUNC requirements for static linkers
IFUNCresolvers must not be compiled with security features like stack-protection, which requires a guard variable to be initialized.
A journey into Radare 2 – Part 2: Exploitation – Megabeets
GCC compiling with -no-pie and -fno-stack-protector options to disable protection mechanisms on the stack.
Stack Canaries#
How to look at the stack with gdb
The canary is pretty clever: it starts with a null byte so that it won't be leaked by normal string functions, and the true canary is stored somewhere else in memory (not the stack) so it can't be easily leaked or corrupted.
Stack Canaries | Binary Exploitation
Stack Canaries are very simple - at the beginning of the function, a random value is placed on the stack. Before the program executes ret, the current value of that variable is compared to the initial: if they are the same, no buffer overflow has occurred.
If they are not, the attacker attempted to overflow to control the return pointer and the program crashes, often with a stack smashing detected error message.
Programming with 64-Bit ARM Assembly Language | Chapter 16: Hacking Code - Mitigating Buffer Overrun Vulnerabilities - Poor Stack Canaries Are the First to Go
The GNU C compiler has a feature to detect buffer overruns. The idea is, in any routine that contains a string buffer located on the stack, to add extra code to place a secret random value next to the stored function return address. Then this value is tested before the function returns, and if corrupted, then a buffer overrun has occurred, and the program is terminated. These stack canaries are like the proverbial canaries in a coal mine, because when something goes wrong, they're the first to go and warn us that something bad is happening.
Reverse Engineering for Beginners(Understanding Assembly Language) @PDF
- Code Patterns - Arrays - Buffer overflow protection methods
One of the methods is to write a random value between the local variables in stack at function prologue and to check it in function epilogue before the function exits. If value is not the same, do not execute the last instruction RET, but stop (or hang). The process will halt, but that is much better than a remote attack to your host.
This random value is called a "canary" sometimes, it is related to the miners' canary, they were used by miners in the past days in order to detect poisonous gases quickly.
Canaries are very sensitive to mine gases, they become very agitated in case of danger, or even die.
Canary detection#
pwndbg - canary: Print out the current stack canary.
GEF - checksec: The checksec command is inspired from checksec.sh. It provides a convenient way to determine which security protections are enabled in a binary.
GEF - canary: If the currently debugged process was compiled with the Smash Stack Protector (SSP) - i.e. the -fstack-protector flag was passed to the compiler, this command will display the value of the canary. This makes it convenient to avoid manually searching for this value in memory.
radare2's i command(rabin2 -I) can retrieve binary information from opened file, including mitigation properties.
i ~ canary: check if the binary has canariesi ~ nx: check if the binary has non-executable stacki ~ pic: check if the binary has position-independent-code
$ r2 -Ad xr-struct
[0xaaaac5ab0934]> i~canary,crypto,nx,pic,relocs,relro,static,stripped
canary true
crypto false
nx true
pic true
relocs true
relro full
static false
stripped false
Demonstration#
In ARM64 PCS - calling convention and stack layout, pay attention to the disassembly prolog and epilog of foo.
The first prolog instruction creates a space of 0x30/48 bytes for the function, and a guard variable is pushed to the stack base(sp+0x28). The original value is located at offset 0xfe8 of the data segment(LOAD1). The ADRP+LDR instructions form the address of the initial canary.
[0xaaaac5ab0934]> pdf @ sym.foo
# prolog
│ sym.foo + 0 0xaaaac5ab08ac fd7bbda9 stp x29, x30, [sp, -0x30]!
│ sym.foo + 4 0xaaaac5ab08b0 fd030091 mov x29, sp
│ sym.foo + 8 0xaaaac5ab08b4 80000090 adrp x0, map._home_pifan_Projects_cpp_xr_struct.rw_
│ sym.foo + 12 0xaaaac5ab08b8 00f447f9 ldr x0, [x0, 0xfe8]
│ sym.foo + 16 0xaaaac5ab08bc 010040f9 ldr x1, [x0]
│ sym.foo + 20 0xaaaac5ab08c0 e11700f9 str x1, [sp, 0x28]
│ sym.foo + 24 0xaaaac5ab08c4 010080d2 mov x1, 0
│ sym.foo + 28 0xaaaac5ab08c8 e0430091 add x0, var_10h
│ sym.foo + 32 0xaaaac5ab08cc e80300aa mov x8, x0
After sym.foo + 12, we can use ?w x0 or drr ~ x0 to inspect/telescope the guard variable.
When debugging in gdb-pwndbg, type i symbol $x0 to inspect the canary after <foo+12>. The guard variable is labelled as __stack_chk_guard by pwndbg.
pwndbg> i symbol $x0
__stack_chk_guard in section .data.rel.ro of /lib/ld-linux-aarch64.so.1
pwndbg> i addr __stack_chk_guard
Symbol "__stack_chk_guard" is static storage at address 0xfffff7ffdb58.
pwndbg> telescope $x0
00:0000│ x0 0xfffff7ffdb58 (__stack_chk_guard) ◂— 0x9a7d2c706ded4700
01:0008│ 0xfffff7ffdb60 (_rtld_global_ro) ◂— 0x50f9500000000
02:0010│ 0xfffff7ffdb68 (_rtld_global_ro+8) —▸ 0xfffffffff4e8 ◂— 0x34366863726161 /* 'aarch64' */
The LDR+STR instructions load canary from memory and store it to the correct place on the stack.
At the beginning of the epilog, it reloads the initial value from segment.LOAD1+0xfe8 to X1 and loads its copy from stack sp+0x28 to X2. Then the SUBS instruction performs a subtraction and updates the ALU flags, which is equivalent to a comparison to check the correctness of the "canary".
If X2-X1 equals to zero, which means the original "canary" is still there, i.e. the stack hasn't been overwritten/overflowed, b.eq jumps to the success branch. Otherwise the guard check fails, it jumps to __stack_chk_fail.
[0xaaaac5ab0934]> pdf @ sym.foo
# epilog
│ sym.foo + 96 0xaaaac5ab090c 80000090 adrp x0, map._home_pifan_Projects_cpp_xr_struct.rw_
│ sym.foo + 100 0xaaaac5ab0910 00f447f9 ldr x0, [x0, 0xfe8]
│ sym.foo + 104 0xaaaac5ab0914 e21740f9 ldr x2, [var_28h]
│ sym.foo + 108 0xaaaac5ab0918 010040f9 ldr x1, [x0]
│ sym.foo + 112 0xaaaac5ab091c 420001eb subs x2, x2, x1
│ sym.foo + 116 0xaaaac5ab0920 010080d2 mov x1, 0
│ sym.foo + 120 ┌─< 0xaaaac5ab0924 40000054 b.eq 0xaaaac5ab092c
│ sym.foo + 124 │ 0xaaaac5ab0928 6affff97 bl sym.imp.__stack_chk_fail
│ sym.foo + 128 └─> 0xaaaac5ab092c fd7bc3a8 ldp x29, x30, [sp], 0x30
└ sym.foo + 132 0xaaaac5ab0930 c0035fd6 ret
Stack canaries are quite effective, but if a hacker discovers the value used in a running process, they can construct a buffer overrun exploit. Plus, the fact that having your process terminate like this is never a good thing.
